Halo sobat labs, bagaimana kabarnya ? Semoga anda semua sehat selalu ya. Labs, di artikel ini penulis ingin menjelaskan spesifikasi mengenai dua produk dari chemistry analyzer. Keduanya berasal dari brand NB Medical System dan juga Sumifin IChem 533. Nah, kali ini penulis akan share salah satu brand nya dulu, yakni NB Medical System. Untuk penjelasan lebih lanjut, mari simak di bawah ini.
Spesifikasi Alat Chemistry Analyzer

Sebelum kita masuk ke pembahasan, penulis ingin menginformasikan jika anda membutuhkan alat chemistry analyzer ini, bisa anda dapatkan di distributor alat laboratorium. Nah, PT. Andaru Analitika Sains sebagai distributor alat laboratorium juga menyediakan alat chemistry analyzer tersebut dan berbagai macam alat general laboratorium lainnya seperti disintegration tester, friability tester, hardness tester, dissolution tester, biosafety cabinet, mikroskop, mikropipet, autoclave, centrifuge, water bath.
Untuk informasi lebih lanjut, anda bisa menghubungi kontak yang tersedia via WhatsApp : 0877 7727 7740 atau Telepon (0251) 7504679. Link alamat juga kami cantumkan disini google maps.
Spesifikasi Chemistry Analyzer NB Medical System MS-380P
Model | MS-380P |
System | Fully automated, random access chemistry system with STAT capability |
Throughput | 300T/H (450 T/H with ISE) |
Photometry | Mono-chromatic & Bi-chromatic measurements with Multi-wavelength diffraction grating with 13 wavelength options, 340-800 nm |
Simultaneously processed analysis | 79 photometric tests |
Assay Method | 1-Point end, 2-Point end, Fixed, Rate-A and Rate-B |
Calibration | Linear, Non-linear, Multipoint, K factor |
Absorbonce Range | 0-3. 8A |
Sample types | Serum, plasma, urine and others |
Sample disk capacity | Sample tray. Ring : 79 positions for routine samples (all position can be used for STAT samples) |
Sample Volume | 1.5-20µ in 0.1 µ step |
Sample Cups | Sample cups and sample tubes in different sizes |
Reagent tray capacity | 80 refrigerating reagent positions |
Reagent storage | 4°C – 12°C |
Mixing Function | Independent stirring arms |
Reagent Volume | 15-200 µ in 0.5 µ step |
Reaction Cuvette | Cuvette made of UV free plastic |
Min. Reaction Volume | 75 µ |
Reaction Time | 10min or 22min |
Reaction Incubation | 37°C, water bath |
Light Source | Long – life halogen lamp |
Barcode Reader | Optional |
Rinse | Automatic washing and drying |
Operation system | All Windows systems |
Dimensions and weight | 1040(W) X 780 (D) x 1200(H) mm, Approx 250kg
1260(W)x870(D) x 1160(H)mm, Approx 360kg |
Power Supply | 220/110V , 50/60Hz |
Fitur
- Random access function for emergency analysis is available
- High accuracy
- Required sample/reagent volume reduced to a very low range
- High performance
- Reliability with the volume tracking technology , real-time monitoring the reagent level.
Ditulis Oleh : DNA
Sampai disini dulu artikel mengenai ” Spesifikasi Chemistry Analyzer “. Untuk informasi lengkap mengenai alat ini, anda bisa kunjungi artikel Chemistry Analyzer . Semoga artikel ini dapat bermanfaat bagi anda, sampai jumpa di artikel berikutnya.
